Fraise à bille à 2 cannelures pour aluminium
Matériau de la pièce
Spécification et application
| Données techniques | |
|---|---|
| Grade | AL700 |
| En magasin | Oui |
| Comment commander | Contactez-nous |
| Télécharger toutes les spécifications | Télécharger |
| N° de commande | R (¹/2 D) [mm] | FL [mm] | TL [mm] | SD h6 [mm] |
|---|---|---|---|---|
| AL700BT2-R0.50 | R0.50 | 2.0 | 50 | 4 |
| AL700BT2-R0.75 | R0.75 | 3.0 | 50 | 4 |
| AL700BT2-R1.00 | R1.00 | 4.0 | 50 | 4 |
| AL700BT2-R1.25 | R1.25 | 5.0 | 50 | 4 |
| AL700BT2-R1.50-D3 | R1.50 | 6.0 | 50 | 3 |
| AL700BT2-R1.50 | R1.50 | 6.0 | 50 | 4 |
| AL700BT2-R1.75 | R1.75 | 7.0 | 50 | 4 |
| AL700BT2-R2.00 | R2.00 | 8.0 | 50 | 4 |
| AL700BT2-R2.50 | R2.50 | 10.0 | 50 | 6 |
| AL700BT2-R3.00 | R3.00 | 12.0 | 50 | 6 |
| AL700BT2-R3.50 | R3.50 | 17.0 | 60 | 8 |
| AL700BT2-R4.00 | R4.00 | 16.0 | 60 | 8 |
| AL700BT2-R5.00 | R5.00 | 20.0 | 75 | 10 |
| AL700BT2-R6.00 | R6.00 | 24.0 | 75 | 12 |
| AL700BTL2-R0.50 | R0.50 | 2.00 | 75 | 4 |
| AL700BTL2-R0.75 | R0.75 | 3.00 | 75 | 4 |
| AL700BTL2-R1.00 | R1.00 | 4.00 | 75 | 4 |
| AL700BTL2-R1.50-D3 | R1.50 | 6.00 | 75 | 3 |
| AL700BTL2-R1.50 | R1.50 | 6.00 | 75 | 4 |
| AL700BTL2-R2.00 | R2.00 | 8.00 | 75 | 4 |
| AL700BTL2-R3.00 | R3.00 | 12.00 | 75 | 6 |
| AL700BTL2-R4.00 | R4.00 | 16.00 | 75 | 8 |
| AL700BTF2-R0.50 | R0.50 | 2.00 | 100 | 4 |
| AL700BTF2-R1.00 | R1.00 | 4.00 | 100 | 4 |
| AL700BTF2-R1.50 | R1.50 | 6.00 | 100 | 4 |
| AL700BTF2-R2.00 | R2.00 | 8.00 | 100 | 4 |
| AL700BTF2-R3.00 | R3.00 | 12.00 | 100 | 6 |
| AL700BTF2-R4.00 | R4.00 | 16.00 | 100 | 8 |
| AL700BTF2-R5.00 | R5.00 | 20.00 | 100 | 10 |
| AL700BTF2-R6.00 | R6.00 | 24.00 | 100 | 12 |
Fraise en carbure doux :
Forets en carbure doux :
Mèches pour toupie à bois :
- Haute résistance à l'usure
- Réduire le temps machine
- Des performances stables
- Facile à utiliser
